As organizations grow increasingly reliant on cloud-based services and distributed networks, traditional WAN architectures can no longer keep up with the demand for speed, flexibility, and resilience. That’s where FortiGate SD-WAN comes in—a software-defined solution that transforms your WAN infrastructure into a dynamic, intelligent network capable of delivering application-aware routing, better performance, and significant cost savings.

In this guide, we’ll walk through everything you need to know to successfully configure SD-WAN on your FortiGate firewall, from core concepts to advanced settings that can fine-tune performance across multiple WAN links.

Trending

Healthcare IT Project Management: Best Practices for Success

What is FortiGate SD-WAN?

FortiGate SD-WAN is an integrated feature in Fortinet’s next-generation firewalls that replaces traditional WAN routing with a more agile, policy-based system. It allows you to:

• Combine multiple internet or MPLS links into a single virtual interface
• Route traffic dynamically based on application, performance metrics, or business intent
• Monitor real-time link health (latency, jitter, packet loss)
• Optimize bandwidth usage and failover with minimal downtime

Why Use FortiGate SD-WAN?

Here are some of the top reasons organizations switch to FortiGate SD-WAN:

• Improved performance for cloud and SaaS applications (like Microsoft 365, Zoom, and Salesforce)
• Lower WAN costs by replacing expensive MPLS with broadband or LTE
• Centralized management with FortiManager and FortiAnalyzer
• Built-in security with unified threat protection

Before You Begin: Requirements

To follow this configuration guide, ensure you have:

• A FortiGate appliance with FortiOS 6.2 or higher (FortiOS 7.x recommended)
• At least two WAN interfaces (e.g., ISP1 and ISP2)
• Administrative access to the FortiGate GUI or CLI
• A clear understanding of your ISP gateways, bandwidth speeds, and routing needs

Step-by-Step FortiGate SD-WAN Configuration

Let’s get into the practical setup.

Step 1: Enable SD-WAN Feature

1. Go to Network > SD-WAN
2. Click Enable if it’s not already active
3. Add your WAN interfaces (e.g., wan1, wan2) to the SD-WAN interface group

Once added, FortiGate creates a virtual interface called sd-wan that abstracts the physical interfaces.

Step 2: Configure Interface Members

For each WAN interface:

• Set Interface to wan1, wan2, etc.
• Define the gateway IP for each link
• Enter the bandwidth (up/down) to reflect actual ISP speeds
• Optionally set cost or priority to influence routing behavior

Step 3: Set Up Performance SLA

Performance SLAs (Service-Level Agreements) let FortiGate test link quality in real time.

1. Navigate to Network > SD-WAN > Performance SLA
2. Click Create New
3. Name it (e.g., Google-DNS)
4. Target IP: Use something like 8.8.8.8 or 1.1.1.1
5. Protocol: Choose Ping or HTTP
6. Add all SD-WAN members to the SLA test

This helps FortiGate detect link degradation and reroute traffic accordingly.

Step 4: Define SD-WAN Rules (Policy-Based Routing)

SD-WAN rules determine how traffic is routed across WAN links.

1. Go to Network > SD-WAN Rules
2. Create a new rule (e.g., Microsoft365_Routing)
3. Source: Define internal network or user group
4. Destination: Select Application, Internet Services, or specific IP/URL
5. Preferred Member: Choose wan1 or wan2
6. Use Performance SLA to enable dynamic path selection

You can create rules based on:

• Application category (e.g., VoIP, Video)
• User group (for custom routing policies)
• Measured metrics (jitter, latency, loss)

Step 5: Configure SD-WAN Zones (Optional)

Zones allow you to group multiple SD-WAN members for better control.

1. Navigate to Network > Interfaces > SD-WAN Zones
2. Create a new zone (e.g., “Internet-Zone”)
3. Assign both wan1 and wan2 to this zone
4. Apply the zone in SD-WAN rules and firewall policies

This is particularly useful for multi-region or segmented SD-WAN deployments.

Step 6: Adjust Health Checks and Failover Logic

Each SLA target can trigger automatic failover if thresholds are breached.

1. Go to the SLA config you created
2. Set thresholds:
   • Max Latency: e.g., 100ms
   • Max Jitter: e.g., 20ms
   • Max Packet Loss: e.g., 3%
3. When a link exceeds any threshold, FortiGate shifts traffic to the backup link based on your SD-WAN rule settings

You can enable logging for these events under Log & Report > Events.

Step 7: Update Firewall Policies

Ensure your firewall rules use the sd-wan interface instead of the physical wan1 or wan2.

1. Go to Policy & Objects > Firewall Policy
2. Edit your outgoing internet policies
3. Change Outgoing Interface to sd-wan

This is required for SD-WAN rules to apply properly.

Step 8: Monitor and Optimize

Once configured, monitor your SD-WAN in real-time:

• Network > SD-WAN Monitor shows current link usage, health, and active routes
• FortiView > Traffic > Application helps identify top applications
• Use CLI commands like diagnose sys virtual-wan-link health-check to troubleshoot

Advanced Tips and Best Practices

1. Use Application Control with SD-WAN

Enable application control profiles to classify and route traffic more intelligently, especially for critical business apps.

2. Integrate with FortiManager

For multi-site SD-WAN deployments, FortiManager enables centralized SD-WAN orchestration and template-based configuration.

3. Enable BGP with Overlay Networks

If you’re integrating SD-WAN with MPLS or VPNs, use BGP to advertise dynamic routes between branches and data centers.

4. Use the CLI for Precision Tuning

Commands like:

bashCopyEditconfig system virtual-wan-link
  config members
    edit 1
      set gateway x.x.x.x
      set priority 1
    next
  end
end

…allow you to fine-tune failover behavior, interface weights, and more.

Troubleshooting SD-WAN Issues

Common Issues:

• Traffic not routing as expected: Ensure correct SD-WAN rules are in place and firewall policies reference the sd-wan interface
• Failover not triggering: Check SLA target, thresholds, and logs
• Latency spikes on one link: Adjust link cost or remove it from critical application rules

Use CLI commands like:

bashCopyEditdiagnose sys virtual-wan-link service
diagnose sys virtual-wan-link member

…to inspect current states and decision logic.

Final Thoughts

FortiGate SD-WAN is more than just a WAN optimizer—it’s a next-gen solution that fuses performance, resilience, and security into one unified system. Whether you’re trying to lower costs, improve cloud app performance, or ensure seamless failover between links, SD-WAN gives you the control and flexibility you need.

When configured properly, it becomes an intelligent traffic director that reacts to real-time conditions, all while being deeply integrated into FortiGate’s broader security ecosystem.
